Home Product Laser Cutter LC340SF

LC340SF

LC340SF is mainly used in the laser cutting for customized self-adhesive label products from paper or film in octavo or smaller. It can interact seamlessly with digital printing equipment to realize the whole digitalized process and to lead the future of industrialized digital printing.

  • Product Features
  • Technical Parameter
  • PDF Brochure
  • Product Video
Digitalization

Digitalization

Rapid replacement of different cutting images by computer, not only meets the personalized demands, but suits for short run (digital ) printing jobs and post-press processing of large format integrated printing jobs.

High Precision

High Precision

Automatic laser cutting and engraving guarantee high accuracy with zero vibration deviation.

High Efficient

High Efficient

To replace and upgrade traditional mechanical die cutting by laser cutting, save the time for producing and adjusting of traditional cutting dies.

Affordable Cost

Affordable Cost

Model to cut graphics and characters arbitrarily is controlled by computer, mechanical cutting die is not required, operation and maintenance cost is less.

Technical Specifications:LC340SF
Design Type:Sheet-Fed/Flying Mode
Max. Sheet Size:483mmX 340mm
Application Materials:Self-Adhesive Paper
Light Source:CO₂
Laser energy:180W/300W
Positioning Method:Video capture
Max. Cut Range:340mmX340mm
Input File:PLT, DXF
Power Supply:AC220V 50Hz 5-8KW
Working Environment:T25±2°C, RH40%-60%
Net Weight:1500KG
Machine Dimension:3400mmX2200mmX 1800mm

For more information, please download the PDF brochure, or click "Contact" to subscribe

Click download

For more information, please download the PDF brochure, or click "Contact" to subscribe
