MK800SF

MK800SF is a laser cutting machine for format of 600x890mm, typically for users of sheet-fed self-adhesive make-up, carton manufacturing plants and digital printing plants. It fits for cutting of non-standard cardboard and for small batch digital printing on paper or box.

  • Product Features
  • Technical Parameter
  • PDF Brochure
  • Product Video

Digitalization

Digitalization

.

Rapid replacement of different cutting images by computer, not only meets the personalized demands, but suits for short run (digital) printing jobs and post-press processing of large format imposition printing.

Individualization

Individualization

.

It releases the designers' inspiration and uses the software to directly complete the 3D three-dimensional display on the computer to avoid design defects and errors in the production process. Because there is no limitation of knife mold tools, the designer's creative space can be greatly expanded.

High Precision

High Precision

.

Automatic laser cutting and engraving guarantee zero vibration deviation. Video capture technology minimizes the sheet feeding clearance, meanwhile ensures cutting precision.

High Efficient

High Efficient

.

To replace and upgrade traditional mechanical die cutting by laser cutting, save the time for producing and adjusting of traditional cutting dies.

Affordable Cost

Affordable Cost

.

Model to cut graphics and characters arbitrarily is controlled by computer, mechanical cutting die is not required, operation and maintenance cost is less.

Technical Specifications:MK800SF
Design Type:Sheet-Fed/Flying Mode
Max. Sheet Size:600mmX890mm
Application Materials:Self-Adhesive Paper
Light Source:CO₂
Laser energy:180W*2/300W*2
Positioning Method:Video capture
Input File:PLT, DXF
Power Supply:AC380V+N+PE 50Hz 15-18KW
Air Source:pressure 0.6 ~ 0.7Mpa, flow rate> 1 m³/min
Working Environment:T25±2°C, RH40%-60%
Net Weight:3000KG
Machine Dimension:5400mmX 1400mmX 1950mm

For more information, please download the PDF brochure, or click "Contact" to subscribe

Click Download

For more information, please download the PDF brochure, or click "Contact" to subscribe
